Astronomy Specialist

GSO 6" f/9 RITCHEY-CHRETIEN OTA

$799.00
SKU: GSRC6

GSO

Ritchey-Chrétien

5.4 kg




The Ritchey-Chrétien telescope is the most popular optical design used by professional astronomers and astroimagers all over the world. The Hubble Space Telescope itself uses the RC configuration.

All new GSO RC telescopes now come with a focuser upgrade kit allowing you to connect the ZWO & QHY EAF focusers without additional modification.

The Guan Sheng Optical RC's are excellent astrographs with solid build quality and precisely-figured optical surfaces. The concave hyperbolic primary and convex secondary mirrors deliver excellent correction across the field. The low thermal expansion BK7 mirrors have a surface correction of 1/12th Lambda PV or better and have highly reflective dielectric coatings ensuring 95% reflectivity.

The telescope is made with a rigid steel tube and features computer-optimized baffles to eliminate stray light.

The 6" f/9 Ritchey-Chrétien comes with a dual-speed 2" 10:1 Crayford focuser with 41mm of focus travel and includes a 1.25" adapter and a selection of 2" & 1" extension rings to make connecting a variety of imaging accessories straightforward.

The TS-Optics 2" 1x Flattener for RCs is compatible with both the 6" and 8" GSO RC telescopes.

Specifications



Optical design Ritchey-Chrétien
Diameter 152.4 mm
Focal length 1370 mm
Focal ratio f/9
Linear obstruction 76 mm
Corrected field 32 mm
Backfocus distance 159 mm with standard focuser, 254 mm from rear cell
Weight 5.4 kg
Tube outer diameter 191 mm
Tube length 500 mm without focuser
SKU GSRC6



Items included



  • GSO 6" f/9 RC tube
  • 2" dual-speed Crayford focuser
  • Vixen dovetail bar
  • 2 x 1" M90 male to M90 female extension tubes
  • 1 x 2" M90 male to M90 female extension tube
  • Finderscope bracket
  • Dust caps
